TIPE MOBIL |
New Jazz A
|
New Jazz S
|
New Jazz RS
|
|||
MT
|
MT
|
AT
|
MT
|
AT
|
||
MESIN | ||||||
Tipe |
1.5L SOHC, 4 silinder segaris, 16 katup i-VTEC + DBW + Torque Boost Resonator
|
|||||
Sistem Suplai bahan bakar |
PGM-FI (Programmed Fuel Injection)
|
|||||
Diameter x langkah (mm) |
73.0 x 89.4
|
|||||
Isi Silinder (cc) |
1,497
|
|||||
Perbandingan Kompresi |
10,4 : 1
|
|||||
Daya Maksimum [KW(ps)/rpm] |
88(120)/6.600
|
|||||
Momen Puntir Maksimum Kg-m(Nm)/rpm |
14,8(145)/4.800
|
|||||
TRANSMISI | ||||||
Gear Ratio | 1st |
3,461
|
2,995
|
3,461
|
2,995
|
|
2nd |
1,869
|
1,678
|
1,869
|
1,678
|
||
3rd |
1,303
|
1,066
|
1,303
|
1,066
|
||
4th |
1,054
|
0,76
|
1,054
|
0,76
|
||
5th |
0,853
|
0,551
|
0,853
|
0,551
|
||
Reverse |
3,307
|
1,956
|
3,307
|
1,956
|
||
Final Gear |
4,294
|
4,562
|
4,294
|
4,562
|
||
Grade Logic Control |
-
|
●
|
-
|
●
|
||
Active Torque Converter Lock Up |
-
|
●
|
-
|
●
|
||
Shift Hold System |
-
|
●
|
-
|
●
|
||
SISTEM KEMUDI | ||||||
Sistem |
Rack & Pinion dengan Electric Power Streering (EPS)
|
|||||
Paddle Shift |
-
|
●
|
||||
Tilt & Telescopic Streering Wheel |
● Tilt Only
|
●
|
||||
SISTEM REM | ||||||
Depan |
Ventilated Disc
|
|||||
Belakang |
Drum
|
Disc
|
||||
ABS, EBD |
●
|
|||||
SISTEM SUSPENSI | ||||||
Tipe | Depan |
McPherson Strut
|
||||
Belakang |
H-Shape Torsion Beam
|
|||||
DIMENSI | ||||||
Panjang (mm) |
3900
|
3920
|
||||
Lebar (mm) |
1695
|
1695
|
||||
Tinggi (mm) |
1525
|
1525
|
||||
Sumbu Roda (mm) |
2500
|
|||||
Jarak Pijak Depan (mm) |
1490
|
1475
|
||||
Jarak Pijak Belakang (mm) |
1475
|
1460
|
||||
Radius Putar (meter) |
4,7
|
4,9
|
||||
Kapasitas Tangki (liter) |
42
|
|||||
BAN | ||||||
Ban |
175 / 65 R15
|
185 / 55 R16
|
||||
Roda |
Stell 15" x 5 1/2J + Trim
|
Alloy 15" x 5 1/2J
|
Alloy 16" x 6J
|
|||
INTERIOR | ||||||
Multi Information LCD Display (MIL) |
●
|
|||||
Footrest |
-
|
-
|
●
|
-
|
●
|
|
Power door mirrors |
●
|
|||||
Retractable door mirrors |
-
|
●
|
||||
Power outlet |
●
|
|||||
Sunvisor with vanity mirror (front passenger seat) |
-
|
●
|
||||
Double glove box |
●
|
|||||
Drive Arm rest |
-
|
●
|
||||
Green Glass |
●
|
|||||
Front Armrest |
-
|
-
|
●
|
|||
Sistem audio |
Single Din AM/FP3/WMA + AUX Input
|
Double Din AM/FM Single Disc MP3/WMA + USB + AUX Input
|
Double Din AM/FM Single Disc MP3/WMA/AAC + USB + AUX Input
|
|||
Integrated Rear Headrest |
●
|
|||||
Front & Rear Seat Reclining |
● Front Seat Only
|
●
|
||||
ConvenienceHook |
●
|
|||||
Underseat Box |
●
|
|||||
ULTRA Seat |
●
|
|||||
Front Seat Back Pocket (Assistant) |
-
|
●
|
||||
Trunk capacity (VDA) liter |
384 L / 1321 L
|
|||||
EKSTERIOR | ||||||
Rear Combination Lamp |
Bulb
|
LED
|
New Smoke LED
|
|||
Tailgate Spoiler |
-
|
●
|
||||
High Mount Stop Lamp (LED) |
Bulb
|
LED
|
||||
Fog Lamp |
-
|
●
|
||||
Door Mirror |
Black
|
Body Color ( with Turning Signal )
|
||||
Power Retractable Door Mirror |
-
|
●
|
||||
Exhaust Pipe Finisher |
-
|
●
|
||||
Door Handle |
Black
|
Body Color
|
||||
Front Grille |
Hexagonal
|
Chrome
|
Hexagonal + RS Emblem
|
|||
FITUR KESELAMATAN | ||||||
Pedestrian Protection |
●
|
|||||
Side Impact Beam |
●
|
|||||
Dual Front SRS Airbag |
●
|
|||||
Pretensioner & Load Limiter |
●
|
|||||
Sabuk Pengaman | Depan |
3 Point ELR x 2
|
||||
Belakang |
3 Point ELR x 2 + 2 Point ELR x 1
|
|||||
Neck Shock Mitigation Seat |
●
|
|||||
FITUR KEAMANAN | ||||||
Wave Key |
●
|
|||||
Immobilizer |
●
|
|||||
Keyless Entry |
-
|
●
|
||||
Security Alarm (NEW) |
-
|
●
|
